ZXT-33 RAM Guide ZPMC Port Machinery spare parts

ZXT-33 RAM Guide ZPMC Port Machinery spare parts

The ZXT-33 gate valve guide rail is custom-designed for various gate valves and slide gate valves. It is a core guiding component of the valve opening and closing system. Made of precision-machined 304 austenitic stainless steel, it is polished and treated with anti-corrosion coating. It has a robust structure, is wear-resistant and corrosion-resistant. It is manufactured to original factory standards and is compatible with all ZXT-33 valve sizes. It connects the gate and the valve body, guides the gate to move vertically and smoothly, prevents gate offset, jamming and wear, and ensures smooth valve opening and closing and tight sealing. It is suitable for high-temperature, dusty, highly corrosive and humid operating environments such as power plant desulfurization and denitrification, steel plant flue, chemical pipelines, and water conservancy projects, and meets the operational requirements of gate valves for flexible opening and closing and stable operation.
As a key component of valve opening and closing systems, this product is the preferred choice for industry professionals due to its superior materials and precision manufacturing process. Its core functions are guiding and positioning, supporting the gate, and reducing opening and closing friction. It boasts high strength and wear resistance, with a tensile strength ≥520MPa and a hardness of HB180-HB200. Resistant to acids and alkalis and high temperatures, it effectively withstands the corrosive effects of complex industrial conditions, reducing valve failure and maintenance costs. It is compatible with ZXT-33 series gate valves and slide gate valves, allowing for 24-hour continuous operation. This product adheres to original manufacturer standards and complies with GB/T 1220-2019 and ISO 14405:2016 industry standards, maintaining the same quality as the original manufacturer. It can be directly replaced and is easy to install. Precisely matched core technical parameters: guide rail length 500mm±0.3mm, guide rail width 40mm±0.2mm, thickness 8mm±0.1mm, guide groove width 15mm±0.1mm, operating temperature -30℃~120℃, surface roughness Ra≤0.8μm, precise dimensions, smooth guidance, no loosening or jamming during assembly, built-in wear-resistant coating for optimized protection, balancing guidance and sealing performance, adaptable to various complex working conditions, and helping valves operate efficiently and stably.

Basic parameters:

Place of Origin: Shanghai China
Model Number: 1502094601
Material: 40Cr
Size: 80*100*120mm
Color: Golden
Face Material Composition: Galvanized
Weight: 3kg
Product Name: Guide

The ZXT-33 gate valve guide is a core guiding component of valve opening and closing systems, directly affecting the gate’s opening and closing flexibility, sealing performance, and equipment lifespan. We specialize in industrial valve accessories; our products undergo rigorous testing, ensuring reliable quality and comprehensive after-sales service. We support both wholesale and retail procurement, effectively reducing valve downtime and facilitating efficient operation in various industrial settings such as power plants, steel mills, chemical plants, and water conservancy projects.

Get a personalized quote now

*For other spare parts procurement needs, please contact us!
