ODT005935722 Electrical System Control Board Layout Sany SAT40C Dump Truck Parts
ODT005935722 Electrical System Control Board Layout — engineered for the Sany SAT40C articulated dump truck. Serving as the central nervous system of the vehicle, this comprehensive 20-part electrical distribution assembly houses critical circuit protection and computing modules. The complete kit includes dual Fuse & Relay Panels (142999000191A, 142999000192A), the main Motion Controller Assembly (A810201206235), the Mobile Terminal, and the main wiring harness. Genuine OEM and high-quality aftermarket options available for major electrical rebuilds.
Product Details:
ODT005935722 Electrical System Control Board Layout for Sany SAT40C
The ODT005935722 Electrical System Control Board Layout is the master electrical distribution panel designed specifically for the Sany SAT40C Articulated Dump Truck (ADT). This assembly acts as the “central nervous system” of the chassis, routing power from the batteries and alternator to every sensor, lighting circuit, and drivetrain control module on the vehicle.
This master combination group is highly complex, featuring dual fuse and relay boards to protect circuits from voltage spikes, the primary Motion Controller Assembly that dictates heavy drivetrain operations, and the Mobile Terminal for telematics and data logging. We supply the complete ODT005935722 board assembly as well as individual electrical sub-components, allowing electricians to perform modular repairs without replacing the entire panel. Genuine Sany OEM electrical parts and tested aftermarket alternatives are available for global dispatch.
General Assembly Specifications
| Attribute | Specification Details |
|---|---|
| Assembly Part Number | ODT005935722 |
| Assembly Name | Electrical System Control Board Layout (Main Distribution Panel) |
| Compatible Brand | Sany |
| Applicable Machine | SAT40C Articulated Dump Truck |
| Component Type | Chassis Electrical / ECU & Relays |
ODT005935722 Component Parts List (Master Table)
Below is the detailed 20-part breakdown of this electrical control board group according to the official Sany SAT40C parts catalog. You can order the entire pre-wired panel or request pricing for specific internal modules:
| Index | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 142999000191A | Panel, Fuse & Relay | 1 |
| 2 | 142999000192A | Panel, Fuse & Relay | 1 |
| 3 | A810201206235 | Motion Controller Assembly (Main ECU / ECM) | 1 |
| 4 | 140999020009A | Mobile Terminal (Telematics Data Unit) | 1 |
| 5 | ODT005932451 | Distribution Board | 1 |
| 6 | 21052004 | Chase, Wire (Wiring Conduit) | 1 |
| 7 | A210210000002 | Screw | 13 |
| 8 | A210405000005 | Washer | 13 |
| 9 | A210401000015 | Spring Washer | 13 |
| 10 | A210210000026 | Screw | 28 |
| 11 | A210401000013 | Spring Washer | 28 |
| 12 | A210405000004 | Washer | 28 |
| 13 | A210204000122 | Screw | 4 |
| 14 | A210111000084 | Bolt | 2 |
| 15 | 24002323 | Bolt | 6 |
| 16 | 60060564 | Spring Washer | 8 |
| 17 | 60238783 | Washer | 8 |
| 18 | A210307000016 | Nut | 2 |
| 19 | 60154391 | Suction Cup (Vibration Dampening Mount) | 5 |
| 20 | ODT006090522 | Harness (Panel Wiring Harness) | 1 |
Features & Benefits of Our Sany Electrical Components
- Intelligent Drivetrain Management: The inclusion of the A810201206235 Motion Controller provides rapid, high-speed data processing to coordinate transmission shifts, engine RPMs, and hydraulic functions perfectly.
- Complete Circuit Protection: Dual Fuse & Relay Panels (142999000191A / 142999000192A) offer extensive, isolated protection for high-draw lighting and sensor circuits, preventing a single short circuit from crippling the entire vehicle.
- Vibration-Isolated Architecture: Off-road hauling creates severe chassis resonance. This board is mounted using specialized suction cups / rubber mounts (60154391) and an extensive array of spring washers to completely isolate delicate PCBs from mechanical shock.
Ordering & Inquiry Guidelines
- Select Individual Major Assemblies: Given the scale and value of this control board layout, customers frequently order specific modules. Please clearly specify if you need the entire panel assembly, or just an individual ECU unit (e.g., “Index 3: A810201206235 Motion Controller”).
- Provide Machine Serial Number: Electronic control units, wire harnesses, and telematics terminals (Mobile Terminals) are highly specific to the vehicle’s production year and regional emission/software regulations. Providing your Sany SAT40C VIN guarantees 100% plug-and-play fitment and correct software flashing.
- Anti-Static Shipping: All sensitive electronic modules (like the motion controller and distribution board) are packed in strict ESD-safe (anti-static) packaging to prevent electrostatic damage during international transit.
Submit your inquiry today detailing the specific items you need from the ODT005935722 layout group, along with required quantities and your destination port. Our B2B sales team will provide a detailed commercial quote within 1 business day.
