60352073 High Pressure Connector Sany SAT40C Articulated Dump Truck Spare Parts
60352073 High Pressure Connector (also known as the Fuel Inlet Connector or Feed Tube) — compatible with Sany SAT40C articulated dump truck. This high-pressure common-rail fuel system group integrates the inner fuel feed tube and the protective rubber sealing O-ring. Designed to establish a leak-proof fluid pathway through the cylinder head directly to the fuel injector. Genuine Sany OEM and quality aftermarket options are available.
Product Details:
60352073 High Pressure Connector for Sany SAT40C Dump Truck
The 60352073 High Pressure Connector is an essential connection component used within the cylinder head fuel feed assembly of the Sany SAT40C articulated dump truck. In modern common-rail diesel engines, fuel must be delivered at ultra-high pressures (often exceeding 1,800 bar) from the external fuel rail to the fuel injectors located inside the cylinder head. The high-pressure connector serves as the vital bridge, passing through the cylinder head wall to establish a metal-to-metal sealing lock with the fuel injector body, preventing system pressure drops and fuel dilution in the engine oil.
We supply the fully integrated 60352073 connector group as well as the individual replacement connector body and rubber O-ring seal. Both genuine Sany OEM components and high-precision aftermarket alternatives are ready for B2B export shipment.
General Assembly Specifications
| Attribute | Specification Details |
|---|---|
| Assembly Part Number | 60352073 |
| Assembly Name | High Pressure Connector (Fuel Inlet Connector) |
| Compatible Brand | Sany |
| Applicable Machine | SAT40C Articulated Dump Truck |
| Category | Sany Articulated Dump Truck Fuel System Parts |
60352073 Assembly Component Parts List
Below is the detailed parts catalog list for the sub-components of the 60352073 High Pressure Connector as referenced in the Sany SAT40C parts catalog. You can order these individual parts separately as required:
| Index | Part Number | Description / English Part Name | Qty |
|---|---|---|---|
| 1 | 60352072 | High Pressure Connector (Connector Feed Tube Body) | 1 |
| 2 | 160101120068A031 | Rubber Upper O-ring (Note: Documented in Sany parts manual as “Rubber Ubber O-ring”) | 1 |
Features & Benefits of Our High Pressure Connectors
- Metal-to-Metal Precision Sealing: The high-pressure connector body (60352072) is engineered with a spherical, micro-polished tip that forms an exact hydraulic seal when pressed into the fuel injector’s inlet port.
- High-Pressure Rail Containment: Manufactured from robust alloy steel to withstand continuous fuel pressure pulses under heavy mining engine load cycles without fatiguing.
- Engine Oil Isolation: The rubber upper O-ring (160101120068A031) sits tightly in the cylinder head bore, sealing the engine oil on the valve train side from leaking down into the fuel line channels.
Ordering & Technical Guidelines
- Inlet Seat Angle Verification: High-pressure connectors utilize precise seating angles to seal. When ordering a replacement, always ensure your existing feed tube matches part number **60352072** to prevent localized seating leaks.
- Change Seals Upon Re-installation: High-pressure connector O-rings are subjected to high engine temperatures and oil swelling. Always fit a brand-new rubber upper O-ring (item 2) whenever the connector is removed or inspected.
- Keep Components Sealed: High-pressure fuel systems are highly vulnerable to particulate contamination. Keep the connector ports protected with dust caps until the exact moment of torque installation.
Contact us with part number 60352073, your required quantities, and your destination country to receive a commercial quotation within 1 business day.
