160602010144A Air Filter Sany SAT40C Articulated Dump Truck Spare Parts

160602010144A Air Cleaner Canister Assembly for Sany SAT40C

The 160602010144A Air Filter Assembly is the central air filtration housing system engineered for the heavy-duty engine of the Sany SAT40C articulated dump truck. Haul trucks working in heavy mining, quarrying, and dry earthworks are continuously surrounded by high concentrations of abrasive airborne particulate matter. This multi-element canister utilizes a dual-stage filtration layout to prevent even the finest silica dust from reaching the engine cylinder head, ensuring reliable combustion and stopping premature piston ring or cylinder liner abrasion.

This assembly features a rugged cylindrical Housing (160602050044A), a removable Front Cover (160602080002A) with tight-sealing retention latches, and a Rear End Cover (160602080003A). Inside the canister are two progressive filter elements: the large outer Air Filter Main Filter Element (B222100000641) which captures 99.9% of incoming dust, and the smaller inner Air Filter Safety Filter Element (B222100000640) which serves as a secondary failsafe barrier during primary element servicing. We supply both the complete 160602010144A housing assembly and individual replacement inner and outer filter cartridges.

General Assembly Specifications

160602010144A Assembly Component Parts List

Below is the detailed parts catalog breakdown of the 160602010144A Air Filter canister assembly as referenced in the Sany SAT40C technical manual. All listed components can be ordered individually for targeted field service or routine filter element replacements:

Features & Benefits of Our Air Filter Assembly

• Dual-Stage High-Capacity Filtration: Houses the high-surface-area B222100000641 Main Element to screen out large particulates, paired with the internal B222100000640 Safety Element. The safety element serves as a critical back-up barrier if the outer filter ruptures or during change-out procedures.
• Rigid Heat-Resistant Housing: The main housing body (160602050044A) is manufactured from high-impact structural polymer designed to resist deformation under engine bay heat and vibration.
• Tool-Free Access Covers: The front cover (160602080002A) is secured with quick-release structural latches, permitting rapid, tool-free access to the internal filter elements during routine site servicing.
• Highly Sealed Fluid Channels: Features high-integrity molded elastomer gaskets at the mating joint faces, preventing unfiltered air bypass even under high engine intake suction.

Ordering & Technical Maintenance Guidelines

1. Verify Machine Serial Range: Sany SAT40C trucks utilize specific engine models depending on emissions regulations, which may feature varying air filter canister sizes. Please provide your Sany articulated dump truck’s serial prefix with your inquiry so our team can confirm exact structural compatibility.
2. Never Clean the Safety Element: The inner safety filter element (item 3) is a single-use component designed to stay in place. Do not attempt to blow out or clean the safety element with compressed air. It should be replaced with a fresh element after every three primary main element changes.
3. Avoid Direct Air Blow-Out of Main Elements: While some operators blow out main elements with low-pressure air, we advise replacement over cleaning to prevent tearing the micro-fiber pleats, which leads to immediate dust bypass and engine block wear.

Contact us with part number 160602010144A, your desired quantities, and delivery destination to obtain a detailed quote within 1 business day.
