160102130004A087 Electric Control Unit Group Sany SAT40C Articulated Dump Truck Spare Parts

160102130004A087 Electronic Control Unit Group for Sany SAT40C

The 160102130004A087 Electric Control Unit Group (frequently cataloged as the Electronic Control Unit Group) represents a sophisticated integration of precision-engineered components designed to manage engine electronics on the Sany SAT40C articulated dump truck. Articulated dump trucks operate in rigorous mining, earthmoving, and off-road environments where structural components undergo constant, severe mechanical shocks. Central to this group is the high-performance 61021423 Electronic Control Unit (ECU), which serves as the intelligent brain managing fuel injection timing, common-rail pressures, sensor diagnostics, and overall operational efficiency.

Because engine-mounted electronics are vulnerable to thermal conduction and high-frequency structural harmonics, this group features a dedicated ECU Bracket (160102120008A097) and rubberized Support Blocks (160102130003A133) to isolate and cushion the ECU. We supply the fully integrated 160102130004A087 electronic group, including the programmed ECU, brackets, isolation blocks, washers, and high-tensile flange fasteners. Both genuine Sany OEM kits and highly reliable aftermarket options are in stock for rapid international shipping.

General Assembly Specifications

160102130004A087 Assembly Component Parts List

Below is the detailed parts catalog breakdown of the electronic control unit group as referenced in the Sany SAT40C technical manual. All listed components can be ordered individually for targeted field service or electrical repairs:

Features & Benefits of Our ECU Group

• Intelligent Engine Regulation: The high-performance Electronic Control Unit (61021423) features advanced, robust microprocessor circuitry to regulate fuel injection patterns, throttle responses, and sensor diagnostics under heavy loads.
• Engineered Shock Isolation: The rubber-backed support blocks (160102130003A133)—also listed as back-up blocks—dampen extreme mechanical vibrations and structural harmonics, protecting the internal ECU circuit boards from solder fatigue or component failure.
• Durable Bracket Alignment: The thick steel ECU Bracket (160102120008A097) provides a rigid, precisely aligned mounting profile that ensures the wiring harness connectors remain firmly locked.
• Corrosion-Proof Flanged Hardware: Includes high-strength hexagon flange bolts (items 2, 4, and 7) and flat washers to distribute the clamping force evenly, eliminating structural loosening under rugged mining environments.

Ordering & Technical Guidelines

1. Verify ECU Software Programming: Engine control units (61021423) require correct program calibration and flashing to match specific engine displacements, injection parameters, and regional emissions configurations. Please provide your Sany SAT40C’s chassis serial prefix or engine identification plate data so our technical department can verify or pre-program the module before shipment.
2. Never Bypass Damping Support Blocks: When replacing or mounting the ECU, always verify the condition of the rubber support blocks (item 5). Running the engine with worn or missing isolator blocks will transmit excessive block vibration directly to the ECU, which can lead to premature failure.
3. Handle Electrical Connectors with Care: Before connecting the main harness plugs to the newly installed ECU, ensure the multi-pin connector ports are completely free of dust, grease, or moisture to prevent micro-short circuits.

Contact our B2B sales department today with part number 160102130004A087, your required quantities, and delivery destination to receive a detailed quote within 1 business day.
