160102130004A049 Oil-gas Separator Combination Group Sany SAT40C Dump Truck Parts
160102130004A049 Oil-gas Separator Combination Group — engineered for the Sany SAT40C articulated dump truck. This complete crankcase ventilation (CCV) system includes the main fuel/air separator (60038917), oil-gas pre-separator (160102130003A030), return oil pipes, flexible connecting hoses, mounting brackets, and secure hose clamps. Designed to effectively capture oil mist from engine blow-by gases, protecting the turbocharger and reducing overall oil consumption. Genuine OEM and high-quality aftermarket options available.
Product Details:
160102130004A049 Oil-gas Separator Combination Group for Sany SAT40C
The 160102130004A049 Oil-gas Separator Combination Group is a critical engine emissions and crankcase ventilation module designed for the Sany SAT40C Articulated Dump Truck (ADT). During engine operation, high-pressure combustion blow-by gases carry atomized oil droplets into the crankcase. This combination group filters out suspended oil particles and drains the liquid oil back to the oil pan while safely venting or recirculating clean air.
This 19-part master group provides a dual-stage separation layout featuring an oil-gas pre-separator and a primary separator unit, complete with oil return lines, air circuits, mounting brackets, and heavy-duty clamps. We supply the complete 160102130004A049 combination group as well as individual replacement hoses and filter elements to keep your heavy fleet running clean and efficient. Genuine Sany OEM and premium aftermarket options are ready to ship globally.
General Assembly Specifications
| Attribute | Specification Details |
|---|---|
| Group Part Number | 160102130004A049 |
| Group Name | Oil-gas Separator Combination Group (CCV Group) |
| Compatible Brand | Sany |
| Applicable Machine | SAT40C Articulated Dump Truck |
| Component Type | Crankcase Ventilation / Oil Filtration System |
160102130004A049 Component Parts List (Master Table)
Below is the detailed 19-part breakdown of this oil-gas separator group according to the official Sany SAT40C parts catalog. You can order the entire system or request specific individual part numbers:
| Index | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 60326571 | Hexagon Flange Bolt | 2 |
| 2 | 61000122 | Oil-gas Separator Bracket | 1 |
| 3 | 60038917 | Fuel Air Separator (Main Separator Unit) | 1 |
| 4 | 61008354 | Style 1 Hexagon Nut | 2 |
| 5 | 60326573 | Hexagon Flange Bolt | 2 |
| 6 | 60127623 | Tube Clamp | 4 |
| 7 | 160102120008A037 | Oil Circuit Connecting Hose | 1 |
| 8 | 160102130003A033 | Oil-gas Separator Return Oil Pipe | 1 |
| 9 | 160101120009A105 | Spacer | 1 |
| 10 | 160101120009A104 | Pre-separator Oil Return Pipe | 1 |
| 11 | 61021300 | Hexagon Flange Bolt | 2 |
| 12 | 160102130003A032 | Oil Circuit Connecting Hose | 1 |
| 13 | 60230354 | Hex Head Bolt | 1 |
| 14 | 61000712 | Clamp | 1 |
| 15 | 160102130003A034 | Oil Circuit Connecting Hose | 1 |
| 16 | 60272532 | Hose Clamp | 5 |
| 17 | 160102130003A029 | Air Circuit Connection Hose | 1 |
| 18 | 160102130003A030 | Oil-gas Pre-separator | 1 |
| 19 | 160102130003A031 | Oil Circuit Connecting Hose | 1 |
Features & Benefits of Our Sany CCV Systems
- Dual-Stage Separation Protection: The pairing of the pre-separator (160102130003A030) and main separator unit (60038917) efficiently coalesces fine oil vapor, preventing sticky sludge from coating turbocharger compressor wheels and intercoolers.
- Oil & Heat Resistant Hoses: All connecting hoses (Indexes 7, 12, 15, 17, and 19) are constructed from synthetic rubber compounds specially formulated to resist hot engine oil degradation and high engine-bay temperatures.
- Vibration-Isolated Mounting: Includes the OEM mounting bracket (61000122) and heavy-duty clamps (Index 6, 14, and 16) to ensure line routing remains vibration-free and leak-proof on rough haul roads.
Ordering & Inquiry Guidelines
- Select Needed Components: You can order the entire combination group or specify individual replacement parts (e.g., if you only need the main separator 60038917 or specific connecting hoses).
- Inspect Hoses During Servicing: Hardened or cracked rubber hoses can cause unmetered air leaks and oil weeping. It is best practice to replace aged connecting hoses during separator unit replacement.
- Provide Machine Serial Number: Provide your Sany SAT40C VIN or engine serial number to guarantee 100% accurate hose routing and bracket compatibility for your specific truck.
Submit your inquiry today detailing the specific items you need from the 160102130004A049 group, along with required quantities and your destination country. Our B2B sales team will provide a detailed quote and lead time within 1 business day.
