160102130004A040 Front End Cover Combination Group Sany SAT40C Dump Truck Parts
160102130004A040 Front End Cover Combination Group — catalog reference diagram for the Sany SAT40C articulated dump truck. While this master group number represents a virtual assembly, we supply all 9 physical sub-components listed within this group. You can directly order the heavy-duty front end cover (160102130003A011), anchor support, brackets, and precise mounting hardware from our inventory. Genuine OEM and quality aftermarket options available.
Product Details:
160102130004A040 Front End Cover Combination Group for Sany SAT40C
The 160102130004A040 Front End Cover Combination Group serves as the structural reference mapping for the front engine enclosure on the Sany SAT40C Articulated Dump Truck (ADT). This critical assembly protects the engine’s front gear train, timing components, and provides mounting points for auxiliary brackets and anchor supports.
Please Note: In the official Sany catalog, part number 160102130004A040 is classified as a “Virtual Part, Not Available for Purchase”. This means it is a diagram heading rather than a single boxed product. However, we supply every individual component listed within this breakdown. Please use the master table below to identify and request the specific physical parts (such as the main front end cover, brackets, or bolts) you require for your engine repair.
General Assembly Specifications
| Attribute | Specification Details |
|---|---|
| Virtual Group Part Number | 160102130004A040 |
| Group Name | Front End Cover Combination Group |
| Compatible Brand | Sany |
| Applicable Machine | SAT40C Articulated Dump Truck |
| Component Type | Engine Enclosures & Mounting Hardware |
160102130004A040 Component Parts List (Master Table)
Below is the detailed 9-part breakdown of the front end cover combination group. Please reference the specific part numbers below when placing your order with our sales team:
| Index | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 60127684 | Pin | 2 |
| 2 | 160102130003A011 | Front End Cover | 1 |
| 3 | 160102130003A012 | Bracket | 1 |
| 4 | 61000173 | Hexagon Flange Bolt | 6 |
| 5 | 61000172 | Hexagon Flange Bolt | 2 |
| 6 | 61021319 | Hexagon Bolt With Flange Face | 1 |
| 7 | 61028392 | Hex Head Bolt | 2 |
| 8 | 160102130003A013 | Anchor Support | 1 |
| 9 | 160101090035B175 | Hexagon Flange Bolt | 1 |
Features & Benefits of Our Sany Engine Components
- Heavy-Duty Casting: The 160102130003A011 front end cover is manufactured to withstand high temperatures and severe vibrations, ensuring a perfect oil seal for the engine’s front gear train.
- Precision Bracketing: Integrated supports (such as the 160102130003A012 Bracket and 160102130003A013 Anchor Support) maintain strict Sany tolerances for mounting auxiliary engine accessories securely.
- Vibration-Resistant Hardware: Our supply of hexagon flange bolts provides an expanded clamping surface, reducing the risk of bolts loosening during extreme earthmoving operations.
Ordering & Inquiry Guidelines
- Select Individual Part Numbers: Since the main diagram number (160102130004A040) is a virtual group, please specify the exact internal part numbers you need from the table above (e.g., “Index 2: 160102130003A011 Front End Cover”).
- Provide Machine Serial Number: Front engine configurations can occasionally vary by production batch. Provide your Sany SAT40C VIN or engine serial number to guarantee perfect fitment.
- Hardware Replacement: When replacing the front end cover, it is highly recommended by OEMs to replace the high-stress flange bolts (Indexes 4, 5, 6, and 9) to ensure proper gasket compression upon reassembly.
Submit your inquiry today detailing the specific items you need from the 160102130004A040 group, along with required quantities and your destination country. Our B2B sales team will provide a detailed quote and lead time within 1 business day.
Contact us with assembly number 312701846, specific items from the parts book, and your delivery port to get a commercial quote within 24 hours.
