330106015 Corrugated pipe XCMG XDE130 Electric driving dump truck spare parts

The 330106015 corrugated pipe is an original equipment manufacturer (OEM) product from XCMG, specifically designed for XCMG excavators (such as XE60 and XE200GH), loaders, cranes, etc. It addresses the pain points of ordinary corrugated pipes, such as easy delamination, sealing failure, poor vibration resistance, and insufficient temperature resistance. It is a core component for equipment piping connections and maintenance. The product complies with XCMG’s supporting standards and relevant national standards, using high-quality base materials and undergoing precision molding, hot-dip galvanizing/corrosion passivation, and sealing welding processes. It is suitable for high-temperature, high-dust, high-frequency vibration, salt spray corrosion, and oily operating conditions, perfectly matching original equipment and meeting XCMG’s supply chain digitalization requirements.

Core technical parameters

– Product Model: 330106015
– Product Name: Corrugated Pipe (Special Use for XCMG Construction Machinery)
– Material specifications: steel strip reinforced polyethylene/304 stainless steel/fluororubber, 304 stainless steel chromium content ≥18%, nickel content ≥8%, inner diameter 35-220mm, wall thickness 0.23-0.8mm, with matching flanges and gaskets, conforming to relevant standards and XCMG requirements.
– Processing technology: precision forming, hot-dip galvanizing/corrosion passivation, sealing welding, injection molding sealing, no burrs, no delamination, uniform wave pitch, passed airtightness and tensile strength tests, stable operation, and excellent sealing performance.
– Suitable for: XCMG excavators, loaders, cranes, etc., for connection of intake and exhaust systems, hydraulic lines, prestressed pipes, etc., suitable for high temperature and high dust, high frequency vibration, salt spray corrosion, and oily conditions.
– Key parameters: Expansion range ±50mm, tensile strength ≥350MPa, sealing pressure ≤1.6MPa, salt spray test ≥800 hours, inner wall roughness coefficient n=0.009, installation error ≤0.3mm.
– Temperature range: -40℃~280℃, suitable for complex temperature difference conditions of equipment, anti-creep, anti-aging, anti-ultraviolet, oil and corrosion resistant, no brittleness at low temperature, no deformation at high temperature, and can withstand long-term vibration and impact.
– Structural features: Corrugated integrated structure, good flexibility and free expansion, can absorb pipeline displacement and vibration, surface anti-corrosion treatment, rust and corrosion resistant, tight sealing at the ports, not easy to fall off, smooth inner wall to reduce the resistance of small conveying.
– Installation method: Matches XCMG original flange interface, bolt tightening + sealing gasket sealing. Clean the interface before installation, leave 10%-15% expansion space, tighten the bolts in diagonal order, no equipment modification required, easy to disassemble and assemble.
– Service life: ≥8000 hours under normal working conditions, 2-year warranty, corrosion rate ≤0.002mm/year, waterproof, oil-proof and dustproof, no deformation, no cracking, no leakage, and long-term stable flexibility.

We specialize in supplying XCMG components. Our 330106015 corrugated pipe is manufactured according to XCMG’s original factory processes, ensuring precise dimensions and a complete set of accessories. It undergoes rigorous quality inspection and airtightness and tensile strength tests, achieving a pass rate of ≥99.5%, making it a perfect replacement for original parts. Using this product effectively absorbs pipe displacement and vibration, preventing pipe tearing and cracking, improving pipe connection sealing, and reducing maintenance costs.
