330104330 Battery Box Assembly XCMG XDE130 Dump Truck Parts

330104330 Battery Box Assembly for XCMG XDE130

The 330104330 Battery Box Assembly is a highly critical structural and electrical enclosure designed for the XCMG XDE130 Electric Driving Dump Truck. In severe mining applications, battery cells are subjected to intense mechanical shock, chassis twisting, and corrosive environmental elements. This heavy-duty steel enclosure provides a rigid, weather-resistant sanctuary for the truck’s energy storage system.

Unlike a standard automotive battery tray, this master assembly is a complex combination group engineered for maximum vibration dampening and electrical safety. It features over two dozen specialized rubber seats and cushions to float the batteries, heavy-duty pull rods to securely tie down the cells, integrated copper busbars for efficient power routing, and gas springs to allow mechanics to easily open the heavy steel lid. We supply the complete 330104330 assembly as well as individual internal hardware components for targeted fleet maintenance. Genuine XCMG OEM parts and premium aftermarket alternatives are available for global dispatch.

General Assembly Specifications

330104330 Component Parts List (Master Table)

Below is the detailed 31-part breakdown of this battery box assembly according to the official XCMG XDE130 parts catalog. You can order the entire enclosure kit or request specific individual hardware components (such as insulators, busbars, or gas springs):

Features & Benefits of Our XCMG Electrical Enclosures

• Maximum Battery Isolation: Electric drive dump trucks carry massive, heavy battery arrays. This enclosure utilizes nearly 20 dedicated Rubber Seats and Cushions to “float” the batteries inside the steel shell, absorbing lethal chassis vibrations and preventing cracked battery casings.
• Engineered Electrical Safety: Includes integrated Wiring Boards (Index 32), Insulators (Index 29), and pure Copper Busbars (Index 19) to ensure high-voltage power is routed safely and efficiently without risk of arching to the steel chassis.
• Mechanic-Friendly Serviceability: Features two 801737287 Gas Springs (lid struts) and heavy-duty external handles, allowing a single technician to safely open and secure the heavy steel lid during battery testing and terminal maintenance.

Ordering & Logistics Guidelines

1. Select Individual Parts: You can order the entire pre-assembled battery enclosure kit for a rapid chassis rebuild, or specify exact internal part numbers you need from the table above (e.g., if you only need new lid struts, specify “Index 20: 801737287 Gas Spring”).
2. Vibration Hardware Notice: If your battery box has suffered a collision or severe long-term vibration, it is highly recommended to replace all the Rubber Seats (Indexes 1, 12-14, 23-24) as these elastomers degrade and compress over time, losing their shock-absorbing properties.
3. Global Heavy Freight Shipping: The main 330104611 Box Weld Assembly is a bulky, heavy-gauge steel structure. We utilize specialized flat-rack containers and custom protective crating to ensure this critical enclosure arrives securely at your repair facility.

Submit your inquiry today detailing the specific items you need from the 330104330 assembly, along with required quantities and your destination port. Our B2B sales team will provide a detailed commercial quote and freight lead time within 1 business day.
