330103570 Seal Cover Assembly XCMG XDE130 Dump Truck Parts
330103570 Seal Cover Assembly — engineered for the XCMG XDE130 electric driving dump truck. Professionally recognized as the Planetary Outer Hub Cap, this critical drivetrain sealing component protects the final drive reduction gears from harsh mining environments while retaining essential gear oil. The complete 6-part kit includes the heavy-duty Airtight Cover (330106263), Reinforced Seals (803413618), high-pressure O-Ring (803427014), and exact-spec DIN472 retaining hardware. Genuine OEM and high-quality aftermarket options available for final drive overhauls and reseals.
Product Details:
330103570 Seal Cover Assembly for XCMG XDE130
The 330103570 Seal Cover Assembly is a vital drivetrain protection and fluid-retention component designed for the rear electric drive axle of the XCMG XDE130 Electric Driving Dump Truck. Translation Note: While listed in the factory parts manual as a “Seal Cover,” this assembly is professionally recognized as the Planetary Hub Cap or Final Drive End Cover.
Situated at the outermost point of the wheel hub, this heavy-duty steel cover seals the planetary reduction gear assembly. It prevents expensive gear oil from leaking out under high centrifugal forces while completely blocking abrasive silica dust, mud, and water from contaminating the precision sun and ring gears. This comprehensive 6-part combination group provides everything needed for a complete final drive reseal, including the rigid outer cover, specialized reinforced lip seals, massive O-rings, and heavy-duty circlips. We supply the complete 330103570 master assembly as well as individual internal seals to support targeted axle repairs. Genuine XCMG OEM parts and premium aftermarket alternatives are available for global dispatch.
General Assembly Specifications
| Attribute | Specification Details |
|---|---|
| Assembly Part Number | 330103570 |
| Assembly Name | Seal Cover Assembly (Planetary Outer Hub Cap) |
| Compatible Brand | XCMG |
| Applicable Machine | XDE130 Electric Driving Dump Truck |
| Component Type | Drivetrain / Final Drive Sealing Components |
330103570 Component Parts List (Master Table)
Below is the detailed 6-part breakdown of this final drive seal cover assembly according to the official XCMG XDE130 parts catalog. You can order the fully assembled hub cap or request specific individual sealing components:
| Index | Part Number | Description | Qty | Standard / Note |
|---|---|---|---|---|
| 1 | 330106263 | Airtight Cover (Outer Hub Cap / End Plate) | 1 | – |
| 2 | 803413618 | Reinforced Seal (Heavy-Duty Oil Seal) | 2 | – |
| 3 | 330100772 | Baffle Ring (Oil Slinger / Deflector) | 1 | – |
| 4 | 803427014 | O-Ring 255×6 (Perimeter Flange Seal) | 1 | – |
| 5 | 803384675 | End Straight Coupling (Breather/Fill Port Fitting) | 1 | – |
| 6 | 805407988 | Hold Washer 155×4 (Internal Retaining Ring / Circlip) | 1 | DIN472 |
Features & Benefits of Our XCMG Drivetrain Seals
- Absolute Fluid Retention: The combination of the heavy-duty 803413618 Reinforced Seals and the massive 803427014 O-Ring creates an impenetrable barrier, retaining critical gear oil inside the planetary carrier during high-speed, high-heat rotation.
- Severe-Duty Armor: The 330106263 Airtight Cover is cast from thick, impact-resistant steel to survive direct hits from rocks and deep mud ruts, protecting the delicate internal gears from exposure.
- Vibration-Proof Seating: Secured by the exact OEM-spec DIN472 Hold Washer (circlip), ensuring the seal assembly remains perfectly seated and locked into the hub barrel despite severe drivetrain harmonics.
Ordering & Logistics Guidelines
- Multiply by Axle Requirement: A standard rear drive axle utilizes two (2) of these planetary hub caps (one for the left final drive and one for the right). Please verify if you are resealing one or both sides and adjust your order quantity accordingly.
- Mandatory Seal Replacement: If the hub cap is removed for gear inspection or bearing replacement, OEM service protocols strictly dictate that the O-ring (Index 4) and Reinforced Seals (Index 2) must be discarded and replaced with new ones to guarantee a leak-free reassembly.
- Provide Machine Serial Number: Final drive housing diameters and O-ring thicknesses can occasionally vary depending on the production run of the XDE130. Providing your XCMG equipment serial number ensures 100% plug-and-play fitment.
Submit your inquiry today detailing the specific items you need from the 330103570 assembly, along with required quantities and your destination port. Our B2B sales team will provide a detailed commercial quote and freight lead time within 1 business day.
