14190471 Planetary Axis II Assembly Sany SY1350C1C3KH Tracked hydraulic excavator spare parts

14190471 Planetary Axis II Assembly Sany SY1350C1C3KH Tracked hydraulic excavator spare parts

The 14190471 Planetary Shaft II assembly, relying on professional shaft component manufacturing technology and a strict quality control system, is specially designed for the harsh working conditions of construction machinery. It is widely used in the gearboxes, slewing mechanisms, and traveling mechanisms of major construction machinery such as excavators, crawler cranes, and loaders. It is suitable for various complex scenarios such as mining, infrastructure construction, and building hoisting, effectively solving industry pain points such as planetary shaft deformation, wear, breakage, and loosening. It helps improve the transmission efficiency of equipment and extend the service life of the whole machine. It is a core preferred component for maintenance and replacement in the construction machinery aftermarket, and is also one of the popular high-quality parts for foreign trade export and parts wholesale.
As the “core support” of the planetary gear transmission system, the Planetary Shaft II assembly is meticulously crafted in terms of material selection and processing. It utilizes high-strength alloy structural steel and employs multiple machining processes including precision forging, CNC turning, and grinding, combined with heat treatment processes such as carburizing, quenching, and low-temperature tempering. This effectively enhances the overall strength and dimensional accuracy of the assembly. The shaft surface hardness reaches HRC58-62, while the core exhibits excellent toughness, enabling it to withstand heavy loads, impacts, and other complex operating conditions, preventing shaft bending, wear, or breakage. Simultaneously, the shaft structure design is optimized, with precise machining of positioning steps and mounting slots to ensure assembly accuracy with the planetary gears and planetary carriers. This reduces vibration and wear during operation, improves transmission smoothness, and adapts to high-speed, heavy-load, and other complex operational requirements, allowing for long-term stable operation under harsh conditions.

Core technical parameters:

– Product Model: 14190471
– Product Name: Planetary Axle II Assembly
– Compatible models: Excavators, crawler cranes, loaders and other major construction machinery (can be precisely matched according to specific models)
– Material: High-strength alloy structural steel (shaft body), and the matching bearings are made of GCr15 high-quality bearing steel.
– Structure type: Integrated planetary shaft (including matching bearings and positioning components, easy to assemble)
– Surface hardness: HRC58-62 (shaft surface)
– Core hardness: HV380-450
– Machining process: Precision forging, CNC turning, grinding, carburizing and quenching, low-temperature tempering, with a burr-free and rust-free surface.
– Accuracy class: GB/T 10095.1-2008 Class 6
– Shaft diameter: 28mm (for planetary gear inner bore mounting)
– Shaft length: 85mm
– Positioning step diameter: 35mm
– Thread specification: M12×1.5 (for positioning and fixing)
– Maximum allowable torque: 1500 N·m
– Operating temperature: -40℃~140℃
– Service life: ≥12,000 hours (under normal operating conditions)
– Implementation Standards: GB/T 3077-2015, ISO International Quality Certification
– Weight: 2.3kg (precisely adapted to equipment installation load requirements)

The 14190471 Planetary Shaft II assembly, with its superior materials, precision manufacturing process, and accurate technical parameters, is not only suitable for the repair and replacement of planetary transmission mechanisms in various engineering machinery, but also meets the diverse needs of foreign trade export, wholesale of engineering parts, and equipment modification. The product undergoes rigorous factory testing, ensuring that each piece meets quality standards. It boasts advantages such as convenient assembly, wear resistance, excellent rigidity, low maintenance costs, and stable transmission, effectively reducing equipment downtime losses, improving operational continuity, and decreasing maintenance frequency and costs. Furthermore, it works in synergy with planetary gears and planetary carriers to guarantee the overall operational stability of the transmission system.

Get a personalized quote now

1 14185665 Planetary Gear II
2 14190471 Planetary Axis II Assembly
3 JSJ008732767 Wear-bearing pad II
4 14185689 Sales
5 14185511 Planetary Carrier II

*For other spare parts procurement needs, please contact us!
