29547634 Oil level sensor cover Allison spare parts

29547634 Oil level sensor cover Allison spare parts

The 29547634 oil level sensor cover is a core protective accessory specifically designed for Allison transmission oil level sensors. It precisely matches the original equipment manufacturer (OEM) standards and is widely compatible with Allison transmissions and various commercial vehicles, construction machinery, and special vehicles. Its primary function is to protect the top and interface of the Allison transmission oil level sensor. Working in conjunction with the sensor, it seals the sensor interface to prevent transmission fluid leakage and blocks dust, moisture, and impurities from entering the sensor, protecting the sensor’s sensing elements from damage. This ensures the oil level sensor can monitor the transmission fluid level in real time and accurately, providing reliable protection for the safe operation of the transmission lubrication system and meeting Allison transmissions’ core requirements for accurate and reliable oil monitoring.
This product adopts an integrated precision-machined structure, with a design that fits the oil level sensor mounting interface. It features built-in sealing grooves and special seals, making assembly convenient and requiring no complicated tools for installation and replacement. This effectively improves installation and maintenance efficiency, making it particularly suitable for scenarios such as Allison transmission oil level sensor maintenance and routine transmission inspections.

Core technical parameters:

-Part number: 29547634
– Material specifications: Made of 304 stainless steel (or flame-retardant ABS engineering plastic), with optional SUS316 stainless steel to enhance corrosion resistance. Built-in nitrile rubber (NBR) seals, conforming to GB/T 10125-2021 corrosion resistance standard, tensile strength ≥50MPa, hardness HB 180-220.
– Structural parameters: Cover diameter 42±0.1mm, height 18±0.1mm, internal thread specification M24×1.5 (or snap-fit ​​structure adapted to the corresponding sensor interface), sealing groove width 3.5mm, sealing thickness 2mm, dimensional tolerance ≤±0.02mm, surface roughness Ra≤1.6μm, sealing gap after assembly ≤0.01mm.
– Compatible Models: Precisely compatible with Allison 1000/2000/3000 series transmissions, suitable for various commercial vehicles, construction machinery, and special vehicles equipped with this series of transmissions. It is also compatible with various oil level sensors for Allison transmissions (including sensors of models such as 29549755), and can also be used in protection scenarios with other corresponding specifications of oil level sensors.
– Performance: Normal operating temperature -40℃ to +125℃, sealing leakage rate ≤0.001%, protection level up to IP67, can withstand short-term immersion in water up to 1m.
– Product weight: 0.08±0.005kg (standard weight per unit, conforming to original factory specifications, compact size, does not increase the extra load on equipment, easy for batch storage, installation and carrying)
– Service life: Under normal working conditions, the overall service life is ≥8000 hours, the aging resistance of the seals is ≥800 cycles, and after 1000 hours of continuous operation under high temperature, humidity and high vibration conditions, the sealing performance retention rate is ≥95%.

Core advantages:

The 29547634 oil level sensor cover is an original factory specification compatible product with a tight seal, corrosion and temperature resistance, and easy installation. It effectively solves industry pain points such as poor sealing, easy aging, insufficient corrosion resistance, and loose installation associated with traditional oil level sensor covers. Compatible with Allison transmission oil level sensors and various protection scenarios, it is the preferred product for transmission repair, oil level sensor maintenance, and equipment protection parts replacement. We source directly from the manufacturer, strictly control quality, and use 304 stainless steel (or SUS316) with precision machining processes and dedicated seals. Manufactured according to Allison transmission parts design standards, we provide comprehensive after-sales support, support bulk purchases, and offer outstanding cost-effectiveness. This helps purchasers and repair service providers reduce costs and improve efficiency, providing comprehensive protection for Allison transmission oil level sensors and ensuring oil fluid sealing safety.
