ODT007971507 Connecting Plate Lock Pin Sany SAT40C Articulated Dump Truck spare parts

ODT007971507 is an original equipment manufacturer (OEM) connecting plate locking pin, suitable for wheeled construction machinery and heavy-duty mining dump equipment. It is installed on the chassis connecting plate, at the junction of the frame and the rear axle. As a precision locking component, it can fix the connecting plate position, lock the assembly gap, prevent component loosening and displacement, improve problems such as chassis connection play, driving vibration, misalignment, and abnormal connection noise, and avoid failures such as locking pin wear, deformation, breakage, and positioning failure, ensuring tight chassis connection and stable operation.
This product is made of high-strength alloy tempered steel, precision machined in one piece, and treated with CNC precision grinding, quenching hardening, stress relief, and rust-proof and wear-resistant processes. The pin body possesses both hardness and toughness, exhibiting excellent shear resistance, impact resistance, fatigue resistance, and wear resistance. Original factory dimensions are precise and tolerances are tight, ensuring smooth assembly and disassembly, and a secure locking mechanism. It can withstand high-frequency vibration and heavy loads for extended periods, resisting deformation, loosening, corrosion, and failure. This effectively stabilizes chassis connection accuracy, reducing component wear and equipment maintenance costs.

Core technical parameters

– Product Model: ODT007971507
– Product Name: Connecting Plate Locking Pin
– Compatible Brands: Original Equipment Manufacturers for Construction Machinery
– Compatible Equipment: Wheeled construction machinery, heavy-duty mining dump trucks, engineering transportation machinery and equipment
– Installation location: Chassis connecting plate, connection point between the frame and the rear axle
– Core material: High-strength alloy tempered steel
– Core processes: precision turning, CNC grinding, quenching and hardening, tempering and toughening treatment, stress relief, and corrosion and rust prevention treatment.
– Product characteristics: High hardness, good toughness, shear resistance, wear resistance, not easily deformed or broken.
– Machining accuracy: Original factory precision tolerances, pin roundness and straightness, assembly clearance standard
– Core functions: Positioning and fixing connecting plates, locking assembly gaps, preventing structural loosening, and stabilizing chassis connection accuracy.
Assembly advantages: Original factory standard specifications, precise alignment, convenient disassembly and assembly, secure locking, no need for secondary grinding and adaptation.
– Applicable working conditions: heavy-duty mining, earthwork and infrastructure construction, bumpy roads, high-frequency vehicle vibration, damp dust, and alternating high and low temperature conditions.
– Durability: Not prone to fatigue failure under long-term reciprocating stress, wear-resistant and durable, with a long service life.

The ODT007971507 connecting plate locking pin is a genuine, precision-engineered part, offering accurate positioning, secure locking, wear resistance, and impact resistance, suitable for harsh working conditions of various construction machinery. It effectively solves problems such as chassis looseness and abnormal noise during movement, stabilizes chassis structural performance, reduces equipment downtime losses, and is a high-quality genuine part for equipment maintenance, replacement, and bulk procurement.

Get a personalized quote now

1 ODT007972553 A Frame Welding Component
2 A210111000036 Bolt
3 60060548 Washer
4 ODT007971507 Connecting Plate Lock Pin
5 ODT007971643 Spacer Sleeve
6 A210114000035 Bolt
7 A210405000011 Washer
8 ODT007971520 Bear Cover
9 A210804000002 Oil Cup
10 A880807010006 Joint Bearing
11 ODT008126137 Limit Plate
12 A210404000008 Washer
13 A210111000100 Bolt

*For other spare parts procurement needs, please contact us!
